get device attribute value

This block is part of the Home Automaton group and was last modified in core v13.0.8.

Deprecated This block has been deprecated since v0.0.0, please avoid future use.

get device attribute value aqaraconnection Deprecated v13.0.8

With this block you can update a attribute of an device. DEPRECATED from 15.0.0: this block talks to the Aqara CLOUD gateway, so a command travels to Aqara's servers and back to reach a device in the same room, and stops working when the internet does. RUAL is the gateway now: pair Aqara devices to a Zigbee coordinator on the node and use the local home automation blocks (homeassist_*) instead.

In pins 3 + flow

flow
flow
Connection required
aqaraconnection
An authenciated aqara connection
Device ID required
value
The device ID of the device you want to update.
Attribute resource ID required
value
The resource ID of the attribute you want to change.

Out pins 4 + flow

flow
flow
Connection
aqaraconnection
The aqara connection.
Success
condition
If successful, this pin returns true.
Attribute value
value
The attribute value.
Error
value
Error message if the attribute value could not be requested.

Version history

Introduced in v13.0.8.
