access denied

This block is part of the globals group and was last modified in core v15.0.0.

Home automation integration

access denied object v15.0.0

Starts the flow when someone is refused: an unknown card, a wrong PIN, a credential outside its schedule.

In pins 2

device value v15.0.0
Only fire for this door. Leave empty for every door.
room value v15.0.0
Only fire for devices in this room. Leave empty for every room.

Out pins 12 + flow

flow v15.0.0
device object v15.0.0
The full device: id, name, room, type, capabilities, current state.
device id value v15.0.0
Stable platform id, e.g. zigbee:0x00158d0007e1a2b3.
name value v15.0.0
The device's friendly name.
room value v15.0.0
The room the device is assigned to, empty if none.
type value v15.0.0
sensor, light, switch, climate, cover, lock or button.
capability value v15.0.0
Which capability changed, e.g. occupancy, contact, power.
value value v15.0.0
The new value.
previous value v15.0.0
The value before this change, empty on the first report.
at number v15.0.0
Unix seconds the device reported.
actor value v15.0.0
Who: the user or credential name, empty when the reader could not identify them.
method value v15.0.0
How: nfc, pin, wave, mobile, touchpass or manual.
granted condition v15.0.0
True when access was allowed, false when the reader denied it.

Start-of-flow trigger for a FAILED entry. Fires when an access_entry event is denied. Same out-pins as access granted, with granted=false. Use for security alerting: an unknown card at 3am is worth a notification.

unifi

access

security

door

trigger

A refusal is the more interesting half of an access system. access denied fires when a reader rejects something, and the method pin says what was presented. One refusal is somebody holding the wrong card; a run of them at three in the morning is worth waking a person for, which is why this trigger belongs on a notification path rather than only in a log file.

Used in these guides

These documentation pages use or explain this block:

Version history

Introduced in v15.0.0.
