get pickup location details

This block is part of the shipping group and was last modified in core v13.0.9.

get pickup location details v13.0.9

This block is used to request the details of a pickup location.

Pin Pin Type Default
flow
 flow
Connectionrequired
The PostNL connection.		 postnlconnection
Location Coderequired
The location code for the pickup location.		 value
Pin Pin Type Example
flow
 flow
Connectionrequired
The PostNL connection		 postnlconnection
Success
If successful, return true.		 condition
Address
The address of this pickup location.		 object
Delivery options
The delivery options for this pickup location.		 array
Error
Error message if the pickup location could not be requested.		 value
pakketpunt

Core Releases

v13.0.9 This block was introduced in v13.0.9, click here to see the release notes.
Back to shipping Return to the main group to view all sub-groups Back to PostNL Return to the group to view all blocks within this group
