send simple notification

This block is part of the apn group and was last modified in core v10.4.28.

send simple notification v10.4.28

Sends simple notification with basis options

In pins 10 + flow
  • flow
  • connection apnconnection required
  • title value required

    Notification Title

  • message value required

    Notification Message

  • action value required

    Notification Action

  • topic value required

    The App bundle ID

  • device value required

    Token for the device you are trying to notify

  • badge number

    The number shown in the badge

  • collapse id value

    Unique ID for this type, notifications with same ID will be shown combined

  • mutable content condition

    Defines if the notification is mutable

  • payload object

    Adds custom payload to the notification

Out pins 3 + flow
  • flow
  • connection apconnection

    Chainable connection

  • success condition

    Message Send Succeeded

  • error value

    Error message

A typical wiring for send simple notification: a function trigger starts the flow; open connection feeds the connection pin; value feeds the title pin; value feeds the message pin; value feeds the action pin; value feeds the topic pin; value feeds the device pin; the flow out pin feeds debug.

Studio canvas example for the send simple notification block: typical wiring for send simple notification.

Version history

Introduced in v10.4.28.
