base64 to file
This block is part of the files group and was last modified in core v15.0.0.
base64 to file v15.0.0 Accepts a base64 string and returns a file. The file is written to its own directory under /temp/ (/temp/{id}/{filename}) so concurrent conversions never share a name.
- flow
flow - base64 required
valueThe base64 to be transformed to a file
- filename
v15.0.0valueOptional name for the file. Each conversion gets its own directory under
/temp/, so the name only has to be unique within this call. Defaults to a generated id with the extension of the detected mime type.
- flow
flow - success
condition - error
value - file
file
A typical wiring for base64 to file: branch feeds the flow pin; value feeds the value pin; the flow out pin feeds return.
Commonly used with
In production blueprints, this block is most often wired together with:
- return: this block feeds into it. Returns the added custom pins as data-pins on the function execute.
- branch: feeds into this block.
- get fields: feeds into this block. Gets the selected fields from the given object.
Version history
Introduced in v15.0.0.
