loop iterations

This block is part of the foreach group and was last modified in core v10.4.28.

loop iterations execute_function v10.4.28

In pins 2 + flow

flow
flow
Iterations required
number
Concurrency
number
How many iterate functions should be ran at the same time • Min: 0 • Max: 1000
Default 5

Out pins 1 + flow

done
flow
Iterator
execute_function

Runs the iterator function exactly iterations times, passing the 0-based index on the index pin (value and array receive the index number too), and waits for all iterations before done. A nil, non-numeric, zero, or negative iterations input runs zero iterations. Concurrency defaults to 5 (max 1000, serial at 1); exposed_data_output collects truthy exposed returns in iteration order.

for loop

batch

A typical wiring for loop iterations: a function trigger starts the flow; the function out pin wires to an execute block.

Version history

Introduced in v10.4.28.
