update

This block is part of the github group and was last modified in core v10.4.28.

update v10.4.28

In pins 7 + flow
  • flow
  • connection githubconnection required
  • owner value required

    e.g. rual

  • repo value required

    e.g. blueprinting

  • number number required

    e.g. 1842

  • title value required

    e.g. Issue with UI

  • body value required

    e.g. Text of the issue

  • state value required

    open | closed

Out pins 4 + flow
  • flow
  • connection githubconnection
  • success condition
  • data object
  • error value
github

A typical wiring for update: a function trigger starts the flow; open connection feeds the connection pin; value feeds the owner pin; value feeds the repo pin; number feeds the number pin; value feeds the title pin; value feeds the body pin; value feeds the state pin; the flow out pin feeds debug.

Studio canvas example for the update block: typical wiring for update.

Version history

Introduced in v10.4.28.
