nfc card swiped

This block is part of the globals group and was last modified in core v15.0.0.

nfc card swiped v15.0.0

Starts the flow when any NFC card or fob is presented to a reader, whether or not it was accepted.

In pins 3
  • device v15.0.0
    value

    Only fire for this reader. Leave empty for every reader.

  • room v15.0.0
    value

    Only fire for devices in this room. Leave empty for every room.

  • card v15.0.0
    value

    Only fire for this card token or actor. Leave empty for any card.

Out pins 9 + flow
  • flow v15.0.0
    flow
  • device v15.0.0
    object

    The full device: id, name, room, type, capabilities, current state.

  • device id v15.0.0
    value

    Stable platform id, e.g. zigbee:0x00158d0007e1a2b3.

  • name v15.0.0
    value

    The device's friendly name.

  • room v15.0.0
    value

    The room the device is assigned to, empty if none.

  • type v15.0.0
    value

    sensor, light, switch, climate, cover, lock or button.

  • capability v15.0.0
    value

    Which capability changed, e.g. occupancy, contact, power.

  • value v15.0.0
    value

    The new value.

  • previous v15.0.0
    value

    The value before this change, empty on the first report.

  • at v15.0.0
    number

    Unix seconds the device reported.

Start-of-flow trigger on the nfc capability. Fires when a card is presented, BEFORE and regardless of the access decision : a swipe may be denied. The `value` out-pin carries the card token or actor. Use this to react to a specific card ('when my gym fob is tapped, turn on the porch light') independent of whether it unlocks anything.

unifi
nfc
card
fob
badge
door
trigger

Version history

Introduced in v15.0.0.
