connect

This block is part of the stripe group and was last modified in core v15.0.0.

connect v15.0.0

Opens a Stripe connection. Point it at a Stripe service provider so the secret key stays in the provider store and never appears in this blueprint : the API key pin is the older way and leaves the key readable to anyone who can open the flow.

In pins 4 + flow
  • flow
    flow
  • provider
    value

    Name of a Stripe service provider (Settings → Service Providers). Preferred: the secret key is resolved when a call is made and never lands on a pin.

  • api key
    value

    A literal Stripe secret key (sk_live_… or sk_test_…). Only used when no provider is named. Stored in plaintext in this blueprint.

  • connected account
    value

    Optional. Act on behalf of a Stripe Connect account (acct_…). Overrides the provider's own setting.

  • api version
    value

    Optional. Pins the Stripe API version for every call on this connection.

Out pins 3 + flow
  • flow
    flow
  • connection
    stripeconnection
  • success
    condition

    False when the named provider does not exist, is disabled, or is not a Stripe provider.

  • error
    value
stripe
payment
card
checkout
subscription
billing

Version history

Introduced in v15.0.0.

Service documentation

External API reference This block wraps a third-party service. Click here for the service's own documentation of the underlying endpoint.
