remove network acl

This block is part of the virtualisation group and was last modified in core v13.0.9.

remove network acl v13.0.9

Starts a network acl remove operation on the LXD server.

Pin Pin Type Default
flow
 flow
Connectionrequired
The LXD connection		 lxdconnection
Network ACL namerequired
The name of the network ACL you want to remove.		 value
Pin Pin Type Example
flow
 flow
Connectionrequired
The LXD connection		 lxdconnection
Success
If successful, this pin returns true.		 condition
Error
Error message if the network ACL could not be removed.		 value
delete network

Core Releases

v13.0.9 This block was introduced in v13.0.9, click here to see the release notes.
Back to virtualisation Return to the main group to view all sub-groups Back to LXD Return to the group to view all blocks within this group
