get network acls
This block is part of the virtualisation group and was last modified in core v15.0.0.
get network acls v13.0.9 Updated v15.0.0Retreives all the networks ACLS on LXD server.
In pins 1 + flow
- flow
flow - Connection required
lxdconnectionThe LXD connection
Out pins 4 + flow
- flow
flow - Connection
lxdconnectionThe LXD connection
- Success
conditionIf successful, this pin returns true.
- Networks ACLS
arrayThe networks ACLS on the server.
- Error
valueError message if the networks ACLS could not be requested.
A typical wiring for get network acls: a function trigger starts the flow; create network feeds the connection pin; the flow out pin feeds debug.
Version history
Introduced in v13.0.9.
Last modified in v15.0.0.
