replace
This block is part of the value group and was last modified in core v10.4.28.
replace v10.4.28 Returns a new value with one, some, or all matches of a pattern replaced by a replacement
- Value required
value - pattern required
valueA value to be replaced or a regular expression pattern, prefixed with flags (g, i, m)
- replacement required
valueReplace the substring matched by pattern
- Value
value
When substr is not of the form /pattern/flags it is a literal, case-SENSITIVE search and only the FIRST occurrence is replaced. A /pattern/flags value runs as a JS-style regex; ALL occurrences are replaced only with the g flag. A leading slash without a closing slash plus valid flag letters (e.g. the path "/api/v1") is treated as a literal, and an invalid regex outputs the input unchanged.
A typical wiring for replace: value feeds the value pin; convert to uppercase feeds the substr pin; the value out pin feeds substring.
Commonly used with
In production blueprints, this block is most often wired together with:
- value: feeds into this block. Simply returns the provided value.
- replace: wired in both directions with this block. Returns a new value with one, some, or all matches of a pattern replaced by a replacement.
- fields: this block feeds into it.
- substring: this block feeds into it.
- convert to uppercase: feeds into this block.
- set fields: this block feeds into it. Generates an array of mutations based on the given filled fields.
Version history
Introduced in v10.4.28.
