range
This block is part of the array group and was last modified in core v10.4.28.
range v10.4.28 Generates a new array based on the given start and end numbers.
In pins 3
- start required
numberInput pin for the starting number.
- end (excl.) required
numberInput pin for the ending number. The number will not be taken into account for the range.
- step
numberOptional input pin for the step value (default is 1).
Out pins 1
- array
arrayOutput pin for the generated array based on the provided range.
Generates numbers starting at start, advancing by step (default 1), stopping BEFORE the value of the length pin - length is the EXCLUSIVE end bound, NOT an element count. A negative step counts down while above the end. If the step direction can never reach the end, outputs []. Example: start 0, length 5, step 2 -> [0,2,4].
Version history
Introduced in v10.4.28.
