switch
This block is part of the array group and was last modified in core v10.4.28.
switch v10.4.28 returns an array based of the given expression.
In pins 2
- expression required
valueThe expression to evaluate.
- default
arrayThe default statement to be executed.
Out pins 2
- output
arrayReturns the array matching the expression.
- match
conditionReturns true in case a match was found.
Evaluates the expression against the configured cases and outputs the array wired to the matching case, with matched=true. When no case matches, the default pin's array is output with matched=FALSE - matched reports a non-default hit, not whether an output exists. With no match and no default, array is null and matched is false.
Version history
Introduced in v10.4.28.
