open connection

This block is part of the Home Automaton group and was last modified in core v13.0.8.

Deprecated This block has been deprecated since v0.0.0, please avoid future use.

open connection aqaraconnection Deprecated v13.0.8

This interface is used to open a connection to the Aqara service. DEPRECATED from 15.0.0: this block talks to the Aqara CLOUD gateway, so a command travels to Aqara's servers and back to reach a device in the same room, and stops working when the internet does. RUAL is the gateway now: pair Aqara devices to a Zigbee coordinator on the node and use the local home automation blocks (homeassist_*) instead.

In pins 4 + flow

flow
flow
App ID required
value
Appid of the third-party application
Key ID required
value
appKey corresponds to Keyid
App Key required
value
AppKey of the third-party application
Access Token
value
Access Token obtained through authorization, if not given the connection can only be used for doing authorization requests.

Out pins 3 + flow

flow
flow
Connection
aqaraconnection
The aqara connection
Success
condition
If successful, return true.
Error
value
Error message if the connection could not be established.

Version history

Introduced in v13.0.8.
