execute scene

This block is part of the Home Automaton group and was last modified in core v13.0.8.

Deprecated This block has been deprecated since v0.0.0, please avoid future use.

execute scene aqaraconnection Deprecated v13.0.8

With this block you can execute a scene. DEPRECATED from 15.0.0: this block talks to the Aqara CLOUD gateway, so a command travels to Aqara's servers and back to reach a device in the same room, and stops working when the internet does. RUAL is the gateway now: pair Aqara devices to a Zigbee coordinator on the node and use the local home automation blocks (homeassist_*) instead.

In pins 2 + flow

flow
flow
Connection required
aqaraconnection
An authenciated aqara connection
Scene ID required
value
The ID of the scene you want to execute.

Out pins 3 + flow

flow
flow
Connection
aqaraconnection
The aqara connection.
Success
condition
If successful, this pin returns true.
Error
value
Error message if the scene could not be executed.

Version history

Introduced in v13.0.8.
