generate barcode

This block is part of the shipping group and was last modified in core v13.0.9.

generate barcode postnlconnection v13.0.9

This block is used to request a PostNL barcode for a shipment.

In pins 3 + flow

flow
flow
Connection required
postnlconnection
The PostNL connection.
Barcode Type required
value
The type of the barcode you want to request.
Barcode Serie
value
The serie of the barcode you want to request.
Default 0000000-9999999

Out pins 5 + flow

flow
flow
Connection
postnlconnection
The PostNL connection
Success
condition
If successful, return true.
Barcode
value
The generated PostNL barcode.
Request response
object
The response from PostNL.
Error
value
Error message if the barcode could not be requested.

A typical wiring for generate barcode: a function trigger starts the flow; open connection feeds the connection pin; value feeds the barcode_type pin; the flow out pin feeds debug.

Studio canvas example for the generate barcode block: typical wiring for generate barcode.

Version history

Introduced in v13.0.9.
