open connection

This block is part of the saltedge group and was last modified in core v13.0.6.

open connection saltedgeconnection v13.0.6

Builds a new flow based of the given SaltEdge v5 API Service Key

In pins 3 + flow

flow
flow
App Id required
value
The SaltEdge App Id created within your dashboard
Secret required
value
The SaltEdge App Secret created within your dashboard
Private Key required
value
The private key of the PEM key generated for the usage within your SaltEdge App

Out pins 1 + flow

flow
flow
connection
saltedgeconnection
The opened SaltEdge connection, which can be used in subsequent SaltEdge functions

A typical wiring for open connection: a function trigger starts the flow; value feeds the service_key_id pin; value feeds the service_secret pin; the flow out pin feeds debug.

Studio canvas example for the open connection block: typical wiring for open connection.

Version history

Introduced in v13.0.6.
