presign put url

This block is part of the object storage group and was last modified in core v15.0.1.

presign put url s3connection v15.0.1

Creates a temporary URL that lets a browser upload one object directly to storage, without the file passing through this server. Not available in a simulation : the URL is a real credential.

In pins 5 + flow

flow
flow
connection required
s3connection
The object storage connection to use, from an open connection block.
bucket
value
Bucket name. Leave empty to use the bucket set on the connection.
key required
value
The object key the URL should grant write access to.
expires in (seconds)
number
How long the URL stays valid. Defaults to 900 (15 minutes); the maximum SigV4 allows is 604800 (7 days).
Default 900
content type
value
Strongly recommended. The uploader must send exactly this Content-Type, which stops the URL being used to store something else.

Out pins 6 + flow

flow
flow
connection
s3connection
The same connection, so it can be passed to the next block.
success
condition
error
value
url
value
The signed URL. Anyone holding it has this access until it expires.
expires at
date
RFC-3339 timestamp at which the URL stops working.
expires in
number
Lifetime in seconds, as applied.

Builds a time-limited URL granting anonymous WRITE of `bucket`/`key`, for direct browser-to-storage uploads. Makes NO network call : pure signing : but is SUPPRESSED in a simulation anyway: minting anonymous write access to a live bucket is a real effect that outlives the dry run, and simulating is a lower bar than a production run. The signature covers the method and the key, so the holder cannot READ with it and cannot write anywhere else. It does NOT cover the body : that is what makes a browser upload possible : so the holder may store ANY BYTES at that key until it expires. Keep `expires_in` short and the key specific. Setting `content_type` BINDS the uploader: the request must carry exactly that Content-Type or the gateway refuses it. That is what stops a URL issued for an image being used to park an HTML document that then serves from the bucket's own origin : set it whenever the URL leaves the server. Default 900s, maximum 604800s (7 days); a larger value is refused, not clamped. success=false with NO_CONNECTION, MISSING_BUCKET, MISSING_KEY, or an out-of-range expiry.

s3 presign upload

direct upload

signed upload url

presigned put

Version history

Introduced in v15.0.1.
