datatable
This block is part of the state ui group and was last modified in core v13.0.6.
Storage Selection Required
This block relies on a storage to perform its storage releated actions. You must manually select the storage you want to use in your flow using the storage selector modal. To access the modal, click the white button on the block.
datatable v13.0.1 Updated v13.0.6A styled table made to display a lot of data using pagination.
- state key
valueThe state to bind the datatable to. If it is updated, the component will re-render
- columns required
fielddefinitionsChoose the columns you want to show
- columns sortable
fielddefinitionsChoose which columns can be sorted, by default we will not do any sortable fields
- search fields
fielddefinitionsFields that will be searched on in addition to the column fields
- return fields
v13.0.8fielddefinitionsFields that will be returned during the search. Should be set if the data sent to the frontend should be limited due to confidential fields.
- row actions
statedatatableconnectionActions that are specific to the row like edit, detail, json, revision or inline edit
- query
queryQuery used as a base for the datatable
- rows per page
numberNumber of results per page in the table
- toolbar
stateContent to be shown within the headers right-side.
- class
uiclassAssigns a CSS class to the element. • Hidden when unused
- style
uistyleApplies inline CSS style to the element • Hidden when unused
- attributes
uiattributesAdds custom attributes to the element. • Hidden when unused
- state
stateReturns the element to the frontend state.
- Map Row
execute_functionThe function will be executed for each row and state pins can be returned to overwrite whats visible.
A typical wiring for datatable: combine feeds the columns pin; the function out pin wires to an execute block.
Version history
Introduced in v13.0.1.
Last modified in v13.0.6.
